3M™ Fire Barrier Sealant IC 15WB+, 20 oz Sausage Pack, One Part, Gun Grade, Intumescent Firestop Sealant, Yellow, 3M 98-0400-5512-5

3M 16560-3

Available to Order

$215.50 /CS

(10/CS)

Overview

3M™ Fire Barrier Sealant IC 15WB+ is a cost-effective, one-part, gun-grade, latex-based, intumescent firestop sealant that dries to form a monolithic firestop seal that also acts as a barrier to airborne sound transmission. 3M™ Fire Barrier Sealant IC 15WB+ firestops through penetrations passing through fire-rated floor, floor/ceiling or wall assemblies, as well as other fire-rated interior building partitions and assemblies (e.g. static construction joints or blank openings). In addition, the unique intumescent property of this material allows 3M™ Fire Barrier Sealant IC 15WB+ to expand and help maintain a firestop penetration seal for up to 3 hours as penetrants are exposed to fire. 3M™  Fire Barrier Sealant IC 15WB+ bonds to most construction substrates, including: gypsum wallboard, concrete, metals, wood, plastic and cable jacketing. No mixing is required.

Product Features

  • Firestop tested up to 3 hours in accordance with ASTM E 814 (UL 1479), ASTM E 1966 (UL 2079) & CAN/ULC-S115
  • Expanded fire protection systems
  • Helps minimize sound transfer*
  • Meets the standards and is deemed FBC™ System Compatible
  • Sag-resistant
  • Halogen-free
  •  Excellent adhesion
  • Re-enterable/repairable
  • Excellent caulk rate
  • Paintable
  • Water clean up

Complies with the intent of LEED® NC-EQ Credit 4.1 for Low-Emitting Materials: Adhesives and Sealants, contains <250 g/L VOC contents (less H2 O and exempt solvents per SCAQMD Rule 1168). *Minimizes noise transfer—STC-Rating of 54 when tested in STC 54-rated wall assembly.

Specifications
General
UOM
CS
Unit Size
1
Pieces Per Unit
10/CS
Weight
2.150000
Color
Yellow
Product Brand
3M
Product Type
Fire Foam & Sealant
Size
20 oz.
Technical
Cordless
No
APPROVALS & LISTING
3m-fire-barrier-sealant-ic-15wb-certification
