ITW Buildex
#10-16 x 1-1/2'' Teks® 3 Steel-to-Steel Self-Drilling Screws, Hex-Unslotted, Climaseal®, 1131000
ITW 1131000
IN STOCK
$275.70 /Box
(3000/Box)
Tek-3 Light Duty Self-Drilling Screws
Features and Benefits:
- Sharp convex drill point has precise cutting edges to improve drill performance with less effort
- Non-walking point provides fast material engagement
- Unique point to thread design extrudes the metal preventing strip out
- Point to thread design maximizes pullout performance and minimizes backout
- Four head styles available to handle various applications
- Climaseal® finish provides excellent corrosion resistance and lower tapping torque
INSTALLATION GUIDELINES
- A standard screw gun with a depth sensitive nosepiece should be used to install Teks. For optimal fastener performance, the screw gun should be a minimum of 4 amps and have a RPM range of 0-2500.
- Adjust the screw gun nosepiece to properly seat the fastener.
- New magnetic sockets must be correctly set before use. Remove chip build-up as needed.
- The fastener is fully seated when the head is flush with the work surface.
- Overdriving may result in torsional failure of the fastener or strip out of the substrate.
- The fastener must penetrate beyond the metal structure a minimum of 3 pitches of thread.
Specifications
General
- Product Type
- Self-Drilling Screw
- UOM
- BX
- Unit Size
- 3000
- Pieces Per Unit
- 3000/BX
- Weight
- 33.390000
- Product Brand
- ITW Buildex
- Product Sub Brand
- TEKS®
- MPN
- 1131000
- COO
- Taiwan (Province of China)
- Product AKA & Related Tags
- TEK Screws, TEKS Screws, TEK SDS, TEK Self-Tapping
Content
- Application & Uses 1
- Stitch roof deck and wall panel sidelaps.
- Application & Uses 2
- HVAC, electrical trim accessories to steel framing.
- Application & Uses 3
- Residential steel frame construction.
- Application & Uses 4
- Brick ties to steel framing.
- Application & Uses 5
- Brick ties to steel framing.
- Features & Benefits 1
- Sharp convex drill point has precise cutting edges to improve drill performance with less effort.
- Features & Benefits 2
- Non-walking point provides fast material engagement.
- Features & Benefits 3
- Unique point to thread design extrudes the metal preventing stripout.
- Features & Benefits 4
- Point to thread design maximizes pullout performance and minimizes backout.
- Features & Benefits 5
- Drills and taps in the broadest range of applications.
- Installation Guideline 1
- A standard screwgun with a depth sensitive nosepiece should be used to install Teks. For optimal fastener performance, the screwgun should be a minimum of 4 amps and have a RPM range of 0-2500.
- Installation Guideline 2
- Adjust screwgun nosepiece to properly seat the fastener.
- Installation Guideline 3
- New magnetic sockets must be correctly set before use. Remove chip build-up as needed.
- Installation Guideline 4
- The fastener is fully seated when the head is flush with the work surface.
- Installation Guideline 5
- Overdriving may result in torsional failure of the fastener or stripout of the substrate.
Technical
- Diameter
- #10
- Length
- 1-1/2"
- Material
- Steel
- Steel Grade
- C1022
- Finish
- Climaseal
- Width Across Flats: Basic
- 5/16
- Drive Type
- Hex, Unslotted
- Head Type
- Hex Washer
- Point Size
- #3
- Tensile Strength
- 1,936
- TPI
- 16
- Tensile (lbf)
- 1,936
- Torque (lbs)
- 61
- Drill - Tap Capacity
- .036-.175
- Installation Tool
- 5/16'' Drive Socket
- Max Material Attachments
- 1.075
- Max Material Range
- .036''-1.075''
- Cordless
- No
Compliance
- DFAR Compliant
- No
- QSLD Compliant
- No
